Specifications
DW-10
Flight Performance
-
Endurance:
o Standard: up to 60 minutes
o Endurance battery: up to 90 minutes
-
Scan area: 1000 ha per flight
-
Cruise Speed: 72 km/h
-
Wind Resistance: up to 12.8 m/s (46 km/h)
-
Communication Range: Up to 10 km standard antenna, BVLOS capable
-
Operating Temp: −15 °C to +40 °C
-
Weather: Light rain tolerant
Airframe & Dimensions
-
Material: EPP with carbon composite reinforced body and wings
-
Wingspan: ~116 cm (detachable for compact transport)
-
Weight (MTOW): < 2.4 kg
-
Transport Size: 80 × 50 × 30 cm backpack
-
Landing: Parachute
-
Assembly Time: < 5 minutes
Payload & Sensors (Modular Bay)
Payload & Sensors (Modular Bay)
-
Standard: 24 MP RGB mapping camera
-
Optional:
o 61MP photogrammetry sensor
o RGB + multispectral for crop analysis
o Gimbal Visible (1280 x 720) + thermal (640 × 480) for inspection & rescue
-
Payload Capacity: ~0.5 kg
